PSTIL S 200 50 ESDB — ESD Wheel with I-let Castor
- Wheel Material:Electrostatic Dissipative (ESD)
- Mount Type:Plate mount
- Wheel Diameter:200.0 mm
- Wheel Width:50.0 mm
- Total Height:248.0 mm
- Top Plate Size:120x94mm
- Hole Pitch:88x63mm
- Hole Size:16x11mm
- Load Capacity:180Kgs
- Castor Material:Mild Steel
Product Description
The PSTIL S 200 50 ESDB is a medium-duty plate-mounted castor built around a 200 x 50 mm electrostatic dissipative wheel with a 78 Shore A hardness, carried on a mild steel body. It is rated to carry loads of up to 180 kg per wheel, making it well suited to electronics manufacturing; esd-sensitive environments; cleanrooms. The castor comes with a 360-degree swivel head for easy manoeuvring, a 120x94 mm mounting plate, 88x63 mm mounting hole spacing and a 16x11 mm bolt hole size. Overall height is 248 mm. In service, it performs well on carpet, concrete, epoxy, operates across a temperature range of -10°C to 55°C, and offers quiet, low-noise running. Ideal for electronics manufacturing, esd-sensitive environments, cleanrooms, computer server rooms equipment.
